Intel 8XC251SA User Manual

A-31
INSTRUCTION SET REFERENCE
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding
Operation: ADD
(WRj) ← (WRj) + (dir8)
ADD Rm,dir16
Binary Mode Source Mode
Bytes: 54
States: 32
[Encoding]
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: ADD
(Rm) ← (Rm) + (dir16)
ADD WRj,dir16
Binary Mode Source Mode
Bytes: 54
States: 43
[Encoding]
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: ADD
(WRj) ← (WRj) + (dir16)
ADD Rm,@WRj
Binary Mode Source Mode
Bytes: 43
States: 32
[Encoding]
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: ADD
(Rm) ← (Rm) + ((WRj))
0 0 1 0 1 1 1 0 s s s s 0 0 1 1 direct addr direct add
0 0 1 0 1 1 1 0 t t t t 0 1 1 1 direct addr direct addr
0 0 1 0 1 1 1 0 t t t t 1 0 0 1 s s s s 0 0 0 0
