8XC251SA, SB, SP, SQ USER’S MANUAL
A-36
Hex Code in: Binary Mode = [Encoding]
Source Mode = [Encoding]
Operation: ANL
(A) ← (A) Λ #data
ANL A,dir8
Binary Mode Source Mode
Bytes: 22
States: 1† 1†
†If this instruction addresses a port (P
x , x = 0–3), add 1 state.
Hex Code in: Binary Mode = [Encoding]
Source Mode = [Encoding]
Operation: ANL
(A) ← (A) Λ (dir8)
ANL A,@Ri
Binary Mode Source Mode
Bytes: 12
States: 23
Hex Code in: Binary Mode = [Encoding]
Source Mode = [A5][Encoding]
Operation: ANL
(A) ← (A) Λ ((Ri))
ANL A,Rn
Binary Mode Source Mode
Bytes: 12
States: 12
Hex Code in: Binary Mode = [Encoding]
Source Mode = [A5][Encoding]
Operation: ANL
(A) ← (A) Λ (Rn)
ANL Rmd,Rms
Binary Mode Source Mode
Bytes: 32
States: 21
[Encoding] 0 1 0 1 0 1 0 1 direct addr
[Encoding] 0 1 0 1 0 1 1 i
[Encoding] 0 1 0 1 1 r r r
