Intel 8XC251SA User Manual

A-37
INSTRUCTION SET REFERENCE
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: ANL
(Rmd) ← (Rmd) Λ (Rms)
ANL WRjd,WRjs
Binary Mode Source Mode
Bytes: 32
States: 32
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: ANL
(WRjd) ← (WRjd) Λ (WRjs)
ANL Rm,#data
Binary Mode Source Mode
Bytes: 43
States: 32
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: ANL
(Rm) ← (Rm) Λ #data
ANL WRj,#data16
Binary Mode Source Mode
Bytes: 54
States: 43
[Encoding]
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: ANL
(WRj) ← (WRj) Λ #data16
[Encoding] 0 1 0 1 1 1 0 0 s s s s S S S S
[Encoding] 0 1 0 1 1 1 0 1 t t t t T T T T
[Encoding] 0 1 0 1 1 1 1 0 s s s s 0000 #data
0 1 0 1 1 1 1 0 t t t t 0 1 0 0 #data hi #data low
