ANL Rm,dir8
Binary Mode Source Mode
Bytes: 43
States: 3† 2†
†If this instruction addresses a port (P
x , x = 0–3), add 1 state.
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: ANL
(Rm) ← (Rm) Λ (dir8)
ANL WRj,dir8
Binary Mode Source Mode
Bytes: 43
States: 43
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: ANL
(WRj) ← (WRj) Λ (dir8)
ANL Rm,dir16
Binary Mode Source Mode
Bytes: 54
States: 32
[Encoding]
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: ANL
(Rm) ← (Rm) Λ (dir16)
ANL WRj,dir16
Binary Mode Source Mode
Bytes: 54
States: 43
[Encoding] 0 1 0 1 1 1 1 0 s s s s 0 0 0 1 direct addr
[Encoding] 0 1 0 1 1 1 10 t t t t 0 1 0 1 direct addr
0 1 0 1 1 1 1 0 s s s s 0 0 1 1 direct direct
