Intel 8XC251SA User Manual

A-133
INSTRUCTION SET REFERENCE
Hex Code in: Binary Mode = [Encoding]
Source Mode = [Encoding]
Operation: XRL
(dir8) ← (dir8) ∀ (A)
XRL dir8,#data
Binary Mode Source Mode
Bytes: 33
States: 3† 3†
†If this instruction addresses a port (P
x , x = 0–3), add 1 state.
Hex Code in: Binary Mode = [Encoding]
Source Mode = [Encoding]
Operation: XRL
(dir8) ← (dir8) ∀ #data
XRL A,#data
Binary Mode Source Mode
Bytes: 22
States: 11
Hex Code in: Binary Mode = [Encoding]
Source Mode = [Encoding]
Operation: XRL
(A) ← (A) ∀ #data
XRL A,dir8
Binary Mode Source Mode
Bytes: 22
States: 1† 1†
†If this instruction addresses a port (P
x , x = 0–3), add 1 state.
Hex Code in: Binary Mode = [Encoding]
Source Mode = [Encoding]
Operation: XRL
(A) ← (A) ∀ (dir8)
[Encoding] 0 1 1 0 0 0 1 0 direct addr
[Encoding] 0 1 1 0 0 0 1 1 direct addr immed. data
[Encoding] 0 1 1 0 0 1 0 0 immed. data
[Encoding] 0 1 1 0 0 1 0 1 direct addr
