XRL A,@Ri
Binary Mode Source Mode
Bytes: 12
States: 23
Hex Code in: Binary Mode = [Encoding]
Source Mode = [A5][Encoding]
Operation: XRL
(A) ← (A) ∀ ((Ri))
XRL A,Rn
Binary Mode Source Mode
Bytes: 12
States: 12
Hex Code in: Binary Mode = [Encoding]
Source Mode = [A5][Encoding]
Operation: XRL
(A) ← (A) ∀ (Rn)
XRL Rmd,Rms
Binary Mode Source Mode
Bytes: 32
States: 21
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
Operation: XRL
(Rmd) ← (Rmd) ∀ (Rms)
XRL WRjd,WRjs
Binary Mode Source Mode
Bytes: 32
States: 32
Hex Code in: Binary Mode = [A5][Encoding]
Source Mode = [Encoding]
[Encoding] 0 1 1 0 0 1 1 i
[Encoding] 0 1 1 0 1 r r r
[Encoding] 0 1 1 0 1 1 0 0 s s s s S S S S
[Encoding] 0 1 1 0 1 1 0 1 t t t t T T T T
