PROGRAMMING
Table 5-10. The Effects of Instructions on the PSW and PSW1 Flags
Instruction Type Instruction
Flags Affected (1), (5)
CY OV AC (2) N Z
Arithmetic
ADD, ADDC, SUB,
SUBB, CMP
XXXXX
INC, DEC X X
MUL, DIV (3) 0 X X X
DA X X X
Logical
ANL, ORL, XRL, CLR A,
CPL A, RL, RR, SWAP
XX
RLC, RRC, SRL, SLL,
SRA (4)
XXX
Program Control
CJNE X X X
DJNE X X
NOTES:
1. X = the flag can be affected by the instruction.
0 = the flag is cleared by the instruction.
2. The AC flag is affected only by operations on 8-bit operands.
3. If the divisor is zero, the OV flag is set and the other bits are meaningless.
4. For SRL, SLL, and SRA instructions, the last bit shifted out is stored in the CY bit.
5. The parity bit (PSW.0) is set or cleared by instructions that change the contents of the
accumulator (ACC, Register R11).
