Intel NUC Board D54250WYB and Intel NUC Board D34010WYB
Technical Product Specification
16
Table 3. Components Shown in Figure 2
Item from
Figure 2 Description
A Back panel connectors
B PCI Express Full-Mini Card connector
C PCI Express Half-Mini Card connector
D SATA 6.0 Gb/s connector
E Front panel dual-port USB 2.0 header (2.0 mm pitch)
F Front panel USB 3.0 connector
G Front panel USB 3.0 connector
H Front panel header (2.0 mm pitch)
I SATA power connector
J Front panel stereo microphone/headphone jack
K BIOS setup configuration jumper
L Consumer Infrared (CIR) sensor
M DDR3L SO-DIMM 2 socket
N DDR3L SO-DIMM 1 socket
O Internal DC power connector

Intel D34010WYK Specifications

General

Maximum Memory	16 GB
Graphics	Intel® HD Graphics 4400
Number of Memory Channels	2
Max Memory Bandwidth	25.6 GB/s
Number of DIMMs	2
Serial Port via Header	Yes
Intel® Visual BIOS	Yes
Consumer Infrared Rx Sensor	Yes
Form Factor	UCFF
Processor Support	4th Generation Intel Core i3/i5 Processors
Memory Type	DDR3L 1333/1600 1.35V SO-DIMM
Storage Interface	SATA
Networking	Gigabit Ethernet
Audio	Intel® HD Audio
Product Collection	Intel NUC Kit
Supported Processor	Intel® Core™ i3-4010U Processor (3M Cache, 1.70 GHz)
Graphics Output	HDMI, Mini DisplayPort
Audio Output	HDMI
Expansion Slots	1 x Half-length mini PCIe
USB Revision	USB 3.0
USB Ports	4x USB 3.0
