Intel D34010WYK User Manual

iii
Board Identification Information
Basic Intel
®
NUC Board D54250WYB Identification Information
AA Revision
BIOS Revision
Notes
G99254-301 WYLPT10H.86A.0021 1,2
Notes:
1. The AA number is found on a small label on the component side of the board.
2. The Intel
®
Core™ i5-4250U processor is used on this AA revision
consisting of the following component:
Device Stepping S-Spec Numbers
Intel Core i5-4250U C0 SR16M
Basic Intel
®
NUC Board D34010WYB Identification Information
AA Revision BIOS Revision Notes
G99257-301 WYLPT10H.86A.0021 1,2
Notes:
1. The AA number is found on a small label on the component side of the board.
2. The Intel
®
Core™ i3-4010U processor is used on this AA revision
consisting of the following component:
Device
Stepping
S-Spec Numbers
Intel Core i3-4010U C0 SR16Q
Specification Changes or Clarifications
The table below indicates the Specification Changes or Specification Clarifications that
apply to the Intel NUC Board D54250WYB and Intel NUC Board D34010WYB.
Specification Changes or Clarifications
Date Type of Change Description of Changes or Clarifications
October 2013 Spec Clarification
• Added Figure 8 to show the front panel connectors.
• Added Figure 14 to show the location of the front panel
Consumer Infrared (CIR) sensor
• Updated the link for BIOS update utilities in Section 3.5.
• Updated the link for BIOS recovery in Section 3.6.
• Added information about length and character restrictions for
HDD passwords in Section 3.8.
• Added Figure 5. 4-Pin 3.5 mm (1/8 inch) Audio Jack Pin Out.

Intel D34010WYK Specifications

General

Maximum Memory	16 GB
Graphics	Intel® HD Graphics 4400
Number of Memory Channels	2
Max Memory Bandwidth	25.6 GB/s
Number of DIMMs	2
Serial Port via Header	Yes
Intel® Visual BIOS	Yes
Consumer Infrared Rx Sensor	Yes
Form Factor	UCFF
Processor Support	4th Generation Intel Core i3/i5 Processors
Memory Type	DDR3L 1333/1600 1.35V SO-DIMM
Storage Interface	SATA
Networking	Gigabit Ethernet
Audio	Intel® HD Audio
Product Collection	Intel NUC Kit
Supported Processor	Intel® Core™ i3-4010U Processor (3M Cache, 1.70 GHz)
Graphics Output	HDMI, Mini DisplayPort
Audio Output	HDMI
Expansion Slots	1 x Half-length mini PCIe
USB Revision	USB 3.0
USB Ports	4x USB 3.0
