Technical Reference
49
2.3 BIOS Security Jumper
CAUTION
Do not move a jumper with the power on. Always turn off the power and unplug the
power cord from the computer before changing a jumper setting. Otherwise, the board
could be damaged.
Figure 13 shows the location of the BIOS Security Jumper. The 3-pin jumper
determines the BIOS Security program’s mode.
Table 22 describes the jumper settings for the three modes: normal, lockdown, and
configuration.
Figure 16. Location of the BIOS Security Jumper

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Intel D34010WYK and is the answer not in the manual?

Intel D34010WYK Specifications

General IconGeneral
Maximum Memory16 GB
GraphicsIntel® HD Graphics 4400
Number of Memory Channels2
Max Memory Bandwidth25.6 GB/s
Number of DIMMs2
Serial Port via HeaderYes
Intel® Visual BIOSYes
Consumer Infrared Rx SensorYes
Form FactorUCFF
Processor Support4th Generation Intel Core i3/i5 Processors
Memory TypeDDR3L 1333/1600 1.35V SO-DIMM
Storage InterfaceSATA
NetworkingGigabit Ethernet
AudioIntel® HD Audio
Product CollectionIntel NUC Kit
Supported ProcessorIntel® Core™ i3-4010U Processor (3M Cache, 1.70 GHz)
Graphics OutputHDMI, Mini DisplayPort
Audio OutputHDMI
Expansion Slots1 x Half-length mini PCIe
USB RevisionUSB 3.0
USB Ports4x USB 3.0
