Technical Reference
41
Table 13 lists the connectors and headers identified in Figure 10.
Table 13. Connectors and Headers Shown in Figure 10
Item from
Figure 10
Description
A PCI Express Full-Mini Card connector
B PCI Express Half-Mini Card connector
C SATA 6.0 Gb/s connector through the PCH
D Front panel dual-port USB 2.0 header (2.0 mm pitch)
E Front panel header (2.0 mm pitch)
F SATA power connector
G BIOS setup configuration jumper
H Internal DC power connector
