Product Description
23
1.5.1.4.1 DisplayPort 1.2 Multi-Stream Transport Daisy-Chaining
Table 5 lists the maximum resolutions available when using DisplayPort 1.2
Multi-Stream Transport.
Table 5. DisplayPort Multi-Streaming Resolutions
DisplayPort Usage
Models
Monitor 1
Monitor 2
Monitor 3
3 Monitors 1920 x 1200 @ 60 Hz 1920 x 1080 @ 60 Hz 1920 x 1080 @ 60 Hz
2 Monitors 2560 x 1600 @ 60 Hz 2560 x 1600 @ 60 Hz
3 Monitors
(with DisplayPort 1.2
hub)
1920 x 1080 @ 60 Hz 1920 x 1080 @ 60 Hz 1920 x 1080 @ 60 Hz
1.5.1.5 Multiple DisplayPort and HDMI Configurations
Multiple DisplayPort and HDMI configurations feature the following:
• Two independent displays
• Single HDMI 1.4a with 4K support
• Single DisplayPort 1.2 with 4K support
• Collage Display
Table 6. Multiple Display Configuration Maximum Resolutions
HDMI
DisplayPort and HDMI
DisplayPort
3840 x 2160 @ 30 Hz 3840 x 2160 @ 60 Hz (DisplayPort)
3840 x 2160 @ 30 Hz (HDMI)
3840 x 2160 @ 60 Hz
Note: Higher resolutions may be achievable but have not been tested on Intel NUC.
For information about Refer to
Multiple display maximum
resolutions
https://www-
ssl.intel.com/content/www/us/en/processors/core/CoreTechnicalResou
rces.html (Generic link)
https://www-ssl.intel.com/content/www/us/en/processors/core/4th-
gen-core-family-desktop-vol-1-datasheet (Specific Link)
1.5.1.6 High-bandwidth Digital Content Protection (HDCP)
HDCP is the technology for protecting high definition content against unauthorized
copy or interception between a source (computer, digital set top boxes, etc.) and the
sink (panels, monitor, and TVs). The PCH supports HDCP 1.4a for content protection
over wired displays (Mini HDMI and Mini DisplayPort).
