Intel NUC Board D54250WYB and Intel NUC Board D34010WYB
Technical Product Specification
22
1.5.1.3 Mini High Definition Multimedia Interface* (Mini HDMI*)
The Mini High-Definition Multimedia Interface (Mini HDMI) is provided for transmitting
uncompressed digital audio and video signals to television sets, projectors and other
video displays. It can carry high quality multi-channel audio data and all standard and
high-definition consumer electronics video formats. The Mini HDMI display interface
connecting the processor and display devices utilizes transition minimized differential
signaling (TMDS) to carry audiovisual information through the same Mini HDMI cable.
The processor HDMI interface is designed according to the High-Definition Multimedia
Interface Specification with 3D, 4K, Deep Color, and x.v.Color. . The maximum
supported resolution is 4096 x 2304, 3840 x 2160 @ 24 Hz or 2560 x1600 @ 60 Hz.
The Mini HDMI port is compliant with the HDMI 1.4a specification.
1.5.1.4 Mini DisplayPort*
DisplayPort is a digital communication interface that utilizes differential signaling to
achieve a high bandwidth bus interface designed to support connections between PCs
and monitors, projectors, and TV displays. DisplayPort is suitable for display
connections between consumer electronics devices such as high definition optical disc
players, set top boxes, and TV displays. The Mini DisplayPort interface supports the
1.2 specification.
The DisplayPort output supports Multi-Stream Transport (MST) which allows for
multiple independent video streams (daisy-chain connection with multiple monitors)
over a single DisplayPort. This will require the use of displays that support
DisplayPort 1.2 and allow for this feature.
DisplayPort technology http://www.displayport.org
