Product Description
35
1.11.2.7 Wake from Consumer IR
CIR activity wakes the computer from an ACPI S3, S4, or S5 state.
1.11.2.8 +5 V Standby Power Indicator LED
The standby power indicator LED shows that power is still present even when the
computer appears to be off. Figure 7 shows the location of the standby power LED.
CAUTION
If AC power has been switched off and the standby power indicator is still lit,
disconnect the power cord before installing or removing any devices connected to the
board. Failure to do so could damage the board and any attached devices.
Figure 8. Location of the Standby Power LED

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Intel D34010WYK and is the answer not in the manual?

Intel D34010WYK Specifications

General IconGeneral
Maximum Memory16 GB
GraphicsIntel® HD Graphics 4400
Number of Memory Channels2
Max Memory Bandwidth25.6 GB/s
Number of DIMMs2
Serial Port via HeaderYes
Intel® Visual BIOSYes
Consumer Infrared Rx SensorYes
Form FactorUCFF
Processor Support4th Generation Intel Core i3/i5 Processors
Memory TypeDDR3L 1333/1600 1.35V SO-DIMM
Storage InterfaceSATA
NetworkingGigabit Ethernet
AudioIntel® HD Audio
Product CollectionIntel NUC Kit
Supported ProcessorIntel® Core™ i3-4010U Processor (3M Cache, 1.70 GHz)
Graphics OutputHDMI, Mini DisplayPort
Audio OutputHDMI
Expansion Slots1 x Half-length mini PCIe
USB RevisionUSB 3.0
USB Ports4x USB 3.0
