Intel Ethernet X520 10GbE Dual Port KX4 Mezz User Manual

SFP+ Devices with Pluggable Optics
82599-based adapters
The Intel® Ethernet Server Adapter X520-2 only supports Intel optics and/or the direct attach cables listed below. When
82599-based SFP+ devices are connected back to back, they should be set to the same Speed setting using Intel
PROSet for Windows or ethtool. Results may vary if you mix speed settings.
NOTE: 82599-Based adapters support all passive and active limiting direct attach cables that comply with SFF-
8431 v4.1 and SFF-8472 v10.4 specifications.
Supplier Type Part Numbers
Intel Dual Rate 1G/10G SFP+ SR (bailed) AFBR-703SDZ-IN2 / FTLX8571D3BCV-IT
82598-BASED ADAPTERS
The following is a list of SFP+ modules and direct attach cables that have received some testing. Not all modules are
applicable to all devices.
NOTES:
:
l
Intel® Network Adapters that support removable optical modules only support their original module type.
If you plug in a different type of module, the driver will not load.
l
82598-Based adapters support all passive direct attach cables that comply with SFF-8431 v4.1 and SFF-
8472 v10.4 specifications. Active direct attach cables are not supported
l
Hot Swapping/hot plugging optical modules is not supported.
l
Only single speed, 10 gigabit modules are supported.
Supplier Type Part Numbers
Finisar SFP+ SR bailed, 10g single rate FTLX8571D3BCL
Avago SFP+ SR bailed, 10g single rate AFBR-700SDZ
Finisar SFP+ LR bailed, 10g single rate FTLX1471D3BCL
Dell 1m - Force 10 Assy, Cbl, SFP+, CU, 10GE, DAC C4D08, V250M, NMMT9
Dell 3m - Force 10 Assy, Cbl, SFP+, CU, 10GE, DAC 53HVN, F1VT9
Dell 5m - Force 10 Assy, Cbl, SFP+, CU, 10GE, DAC 5CN56, 358vv, W25W9
Cisco 1m - Twin-ax cable SFP-H10GB-CU1M
Cisco 3m - Twin-ax cable SFP-H10GB-CU3M
Cisco 5m - Twin-ax cable SFP-H10GB-CU5M
Cisco 7m - Twin-ax cable SFP-H10GB-CU7M
Molex 1m - Twin-ax cable 74752-1101, 74752-9093
Molex 3m - Twin-ax cable 74752-2301, 74752-9094
Molex 5m - Twin-ax cable 74752-3501, 74752-9096
Molex 7m - Twin-ax cable 74752-9098
Molex 10m - Twin-ax cable 74752-9004
Tyco 1m - Twin-ax cable 2032237-2
Tyco 3m - Twin-ax cable 2032237-4
Tyco 5m - Twin-ax cable 2032237-6
Tyco 10m - Twin-ax cable 1-2032237-1

Intel Ethernet X520 10GbE Dual Port KX4 Mezz Specifications

General

Interface	KX4
Data Rate	10 Gbps
Form Factor	Mezzanine
Data Transfer Rate	10 Gbps
Product Type	Network Adapter
Controller	Intel 82599
PCIe Version	2.0
Virtualization	Yes
Operating Temperature	0°C to 55°C
Jumbo Frames	Supported
Ports	Dual Port
