Intel Ethernet X520 10GbE Dual Port KX4 Mezz User Manual

Overview
Welcome to the User's Guide for Intel® Ethernet Adapters and devices. This guide covers hardware and software
installation, setup procedures, and troubleshooting tips for the Intel® Gigabit Server Adapters and Intel® 10 Gigabit
Server Adapters. In addition to supporting 32-bit operating systems, this software release also supports Intel® 64 Archi-
tecture (Intel® 64).
Supported 10 Gigabit Network Adapters
l
Intel® Ethernet X520 10GbE Dual Port KX4 Mezz
l
Intel® Ethernet X520 10GbE Dual Port KX4-KR Mezz
l
Intel® Ethernet Server Adapter X520-2
l
Intel® Ethernet 10G 2P X540-t Adapter
l
Intel® Ethernet 10G 2P X520 Adapter
l
Intel® Ethernet 10G 4P X540/I350 rNDC
l
Intel® Ethernet 10G 4P X520/I350 rNDC
l
Intel® Ethernet 10G 2P X520-k bNDC
Supported Gigabit Network Adapters and Devices
l
Intel® PRO/1000 PT Server Adapter
l
Intel® PRO/1000 PT Dual Port Server Adapter
l
Intel® PRO/1000 PF Server Adapter
l
Intel® Gigabit ET Dual Port Server Adapter
l
Intel® Gigabit ET Quad Port Server Adapter
l
Intel® Gigabit ET Quad Port Mezzanine Card
l
Intel® Gigabit 2P I350-t Adapter
l
Intel® Gigabit 4P I350-t Adapter
l
Intel® Gigabit 4P I350-t rNDC
l
Intel® Gigabit 4P X540/I350 rNDC
l
Intel® Gigabit 4P X520/I350 rNDC
l
Intel® Ethernet Connection I354 1.0 GbE Backplane
l
Intel® Gigabit 4P I350-t Mezz
l
Intel® Gigabit 2P I350-t LOM
l
Intel® Gigabit 2P I350 LOM
l
Intel® Gigabit 4P I350 bNDC
Installing the Network Adapter
If you are installing a network adapter, follow this procedure from step 1.
If you are upgrading the driver software, start with step 6.
1. Review system requirements.
2. Follow the procedure in Insert the PCI Express Adapter in the Server.
3. Carefully connect the network copper cable(s) or fiber cable(s).
4. After the network adapter is in the server, install the network drivers.
5. For Windows*, install the Intel® PROSet software.
6. Testing the Adapter.

Intel Ethernet X520 10GbE Dual Port KX4 Mezz Specifications

General

Interface	KX4
Data Rate	10 Gbps
Form Factor	Mezzanine
Data Transfer Rate	10 Gbps
Product Type	Network Adapter
Controller	Intel 82599
PCIe Version	2.0
Virtualization	Yes
Operating Temperature	0°C to 55°C
Jumbo Frames	Supported
Ports	Dual Port
