Intel Ethernet X520 10GbE Dual Port KX4 Mezz User Manual

Intel® Gigabit Network Daughter Cards
Feature
Intel® Gigabit 4P
X540/I350 rNDC
Intel® Gigabit 4P
X520/I350 rNDC Intel® Gigabit 4P I350 rNDC
Bus Connector
PCI Express 2.0 PCI Express 2.0 PCI Express 2.0
Bus Speed
x4 2 x2 x4
Transmission
Mode/Connector
Twisted copper/RJ-45 Twisted copper/RJ-45 Twisted copper/RJ-45
Cabling
1000Base-T (Category 5) 1000Base-T (Category 5) 1000Base-T (Category 5 or Category 3
on 10 Mbps only)
Power Requirements
5.5 Watts (maximum) @ 3.3 V 10.1 Watts (maximum) @ 12 V 5.5 Watts (maximum) @ 3.3 V
Dimensions
(excluding bracket)
5.3 x 2.7 in.
13.5 x 6.9 cm
4.3 x 3.7 in.
11.0 x 9.3 cm
5.3 x 2.7 in.
13.5 x 6.9 cm
Operating Tem-
perature
32 - 131 deg. F
(0 - 55 deg. C)
32 - 131 deg. F
(0 - 55 deg. C)
32 - 131 deg. F
(0 - 55 deg. C)
MTBF
68 years 65 years 117 years
Available Speeds
10/100/1000
auto-negotiate
10/100/1000
auto-negotiate
10/100/1000
auto-negotiate
Duplex Modes
Full or half at 10/100 Mbps; full
only at 1 Gbps
Full or half at 10/100 Mbps; full
only at 1 Gbps
Full or half at 10/100 Mbps; full only at
1000 Mbps
Standards Con-
formance
IEEE 802.1p
IEEE 802.1Q
IEEE 802.3ab
IEEE 802.3ac
IEEE 802.3ad
IEEE 802.3u
IEEE 802.3x
IEEE 802.3z
ACPI v1.0
PCI Express 1.0a
IEEE 802.1p
IEEE 802.1Q
IEEE 802.3ab
IEEE 802.3ac
IEEE 802.3ad
IEEE 802.3u
IEEE 802.3x
IEEE 802.3z
ACPI v1.0
PCI Express 1.0a
IEEE 802.1p
IEEE 802.1Q
IEEE 802.3ab
IEEE 802.3ac
IEEE 802.3ad
IEEE 802.3u
IEEE 802.3x
IEEE 802.3z
ACPI v1.0
PCI Express 1.0a
Indicator Lights
Two per port:
Activity and Speed
Two per port:
Activity and Speed
Two per port:
Activity and Speed
Regulatory and
Safety
Safety Compliance
l
UL 60950 Third Edition- CAN/CSA-C22.2 No.60950-00 (USA/Canada)
l
EN 60 950 (European Union)
l
IEC 60 950 (International)
EMC Compliance
l
FCC Part 15 - Radiated & Conducted Emissions (USA)
l
ICES-003 - Radiated & Conducted Emissions (Canada)
l
CISPR 22 - Radiated & Conducted Emissions (International)
l
EN55022-1998 - Radiated & Conducted Emissions (European Union)
l
EN55024 - 1998 - (Immunity) (European Union)
l
CE - EMC Directive (89/336/EEC) (European Union)
l
VCCI - Radiated & Conducted Emissions (Japan)
l
CNS13438 - Radiated & Conducted Emissions (Taiwan)
l
AS/NZS3548 - Radiated & Conducted Emissions (Australia/New Zealand)
l
MIC notice 1997-41, EMI and MIC notice 1997-42 - EMS (Korea)

Intel Ethernet X520 10GbE Dual Port KX4 Mezz Specifications

General

Interface	KX4
Data Rate	10 Gbps
Form Factor	Mezzanine
Data Transfer Rate	10 Gbps
Product Type	Network Adapter
Controller	Intel 82599
PCIe Version	2.0
Virtualization	Yes
Operating Temperature	0°C to 55°C
Jumbo Frames	Supported
Ports	Dual Port
