Intel Ethernet X520 10GbE Dual Port KX4 Mezz User Manual

Using the Adapter
Testing the Adapter
Intel's diagnostic software lets you test the adapter to see if there are problems with the adapter hardware, the cabling,
or the network connection.
Tests for Windows
Intel PROSet allows you to run four types of diagnostic tests.
l
Connection Test: Verifies network connectivity by pinging the DHCP server, WINS server, and gateway.
l
Cable Tests: Provide information about cable properties.
NOTE: The Cable Test is not supported on:
l
Intel® Ethernet Server Adapter X520-2
l
Intel® Ethernet X520 10GbE Dual Port KX4
Mezz
l
Intel® Ethernet X520 10GbE Dual Port KX4-
KR Mezz
l
Intel® Ethernet 10G 2P X520 Adapter
l
Intel® Ethernet 10G 2P X520-k bNDC
l
Intel® Ethernet 10G 4P X520/I350 rNDC
l
Intel® Ethernet 10G 2P X540-t Adapter
l
Intel® Ethernet 10G 4P X540/I350 rNDC
l
Intel® Gigabit 4P I350-t Mezz
l
Intel® Gigabit 4P X520/I350 rNDC
l
Intel® Ethernet Connection I354 1.0 GbE
Backplane
l
Intel® Gigabit 4P I350 bNDC
l
Intel® Gigabit 2P I350 LOM
l
Hardware Tests: Determines if the adapter is functioning properly.
NOTE: Hardware tests will fail if the adapter is configured for iSCSI Boot.
To access these tests, select the adapter in Windows Device Manager, click the Link tab, and click Diagnostics. A Dia-
gnostics window displays tabs for each type of test. Click the appropriate tab and run the test.
The availability of these tests is hardware and operating system dependent.
DOS Diagnostics
Use the DIAGS test utility to test adapters under DOS.
Linux Diagnostics
The driver utilizes the ethtool interface for driver configuration and diagnostics, as well as displaying statistical inform-
ation. ethtool version 1.6 or later is required for this functionality.
The latest release of ethtool can be found at: http://sourceforge.net/projects/gkernel.
NOTE: ethtool 1.6 only supports a limited set of ethtool options. Support for a more complete ethtool feature set
can be enabled by upgrading ethtool to the latest version.

Intel Ethernet X520 10GbE Dual Port KX4 Mezz Specifications

General

Interface	KX4
Data Rate	10 Gbps
Form Factor	Mezzanine
Data Transfer Rate	10 Gbps
Product Type	Network Adapter
Controller	Intel 82599
PCIe Version	2.0
Virtualization	Yes
Operating Temperature	0°C to 55°C
Jumbo Frames	Supported
Ports	Dual Port
