Intel Ethernet X520 10GbE Dual Port KX4 Mezz User Manual

Power Require-
ments
5.5 Watts (maximum) @ 3.3 V 10.1 Watts (maximum) @ 12 V 0.6 Watts @ 3.3 V (AUX),
6.3 Watts @ 1.2 V
(VCORE)
Dimensions
3.93 x 3.67 in. 4.3 x 3.7 in. 3.0 x 2.5 in.
Operating Tem-
perature
32 - 131 deg. F (0 - 55 deg. C) 32 - 131 deg. F (0 - 55 deg. C) 32 - 131 deg. F (0 - 55
deg. C)
MTBF
68 years 65 years 147 years
Available
Speeds
2 ports at 10 Gbps/(2 ports at 1 Gbps, see
Intel® Ethernet Gigabit 4P X540/I350
rNDC)
2 ports at 10 Gbps/(2 ports at 1 Gbps, see
Intel® Ethernet Gigabit 4P X520/I350
rNDC)
10 Gbps/1 Gbps
Duplex Modes
Full only Full only Full only
Standards Con-
formance
IEEE 802.1p
IEEE 802.1Q
IEEE 802.3ac
IEEE 802.3ad
IEEE 802.3ae
IEEE 802.3x
ACPI v1.0
PCI Express 1.0a
IEEE 802.1p
IEEE 802.1Q
IEEE 802.3ac
IEEE 802.3ad
IEEE 802.3ae
IEEE 802.3x
ACPI v1.0
PCI Express 1.0a
IEEE 802.1p
IEEE 802.1Q
IEEE 802.3ac
IEEE 802.3ad
IEEE 802.3ap
IEEE 802.3x
ACPI v1.0
PCI Express 2.0
Regulatory and
Safety
Safety Compliance
l
UL 60950 Third Edition- CAN/CSA-C22.2 No.60950-00 (USA/Canada)
l
EN 60 950 (European Union)
l
IEC 60 950 (International)
EMC Compliance
l
FCC Part 15 - Radiated & Conducted Emissions (USA)
l
ICES-003 - Radiated & Conducted Emissions (Canada)
l
CISPR 22 - Radiated & Conducted Emissions (International)
l
EN55022-1998 - Radiated & Conducted Emissions (European Union)
l
EN55024 - 1998 - (Immunity) (European Union)
l
CE - EMC Directive (89/336/EEC) (European Union)
l
VCCI - Radiated & Conducted Emissions (Japan)
l
CNS13438 - Radiated & Conducted Emissions (Taiwan)
l
AS/NZS3548 - Radiated & Conducted Emissions (Australia/New Zealand)
l
MIC notice 1997-41, EMI and MIC notice 1997-42 - EMS (Korea)
Intel® Gigabit Network Adapter Specifications
Feature
Intel® PRO/1000 PT Server
Adapter and Intel®
PRO/1000 PT Dual Port
Server Adapter
Intel®
PRO/1000
PF Server
Adapter
Intel® Gigabit ET Dual Port
Server Adapter and Intel®
Gigabit ET Quad Port Server
Adapter
Intel® Gigabit 2P
I350-t Adapter and
Intel® Gigabit 4P
I350-t Adapter
Bus Connector
PCI Express 1.0a PCI Express
1.0a
PCI Express 2.0 PCI Express 2.0
Bus Speed
PRO/1000 PT Server Adapter:
x1
PRO/1000 PT Dual Port Server
Adapter: X4
x4 x4 x4
Transmission
Mode/Connector
Twisted copper/RJ-45 SX Fiber
Optic/ LC
Twisted copper/RJ-45 Twisted copper/RJ-45

Intel Ethernet X520 10GbE Dual Port KX4 Mezz Specifications

General

Interface	KX4
Data Rate	10 Gbps
Form Factor	Mezzanine
Data Transfer Rate	10 Gbps
Product Type	Network Adapter
Controller	Intel 82599
PCIe Version	2.0
Virtualization	Yes
Operating Temperature	0°C to 55°C
Jumbo Frames	Supported
Ports	Dual Port
