Cabling
1000Base-T (Category 5) 1000Base-
SX (fiber)
1000Base-T (Category 5) 1000Base-T ( Category 3
or Category 5)
Power Require-
ments
3.3 Watts @ +5VDC 3.3 Watts @
+5VDC
Intel® Gigabit ET Dual Port Server
Adapter: 2.9 Watts @ 3.3 V
Intel® Gigabit ET Quad Port
Server Adapter: 9.53 Watts @ 12 V
Intel® Gigabit 2P I350-t
Adapter: 4.8 Watts @ 12
V
Intel® Gigabit 4P I350-t
Adapter: 6.0 Watts @ 12
V
Dimensions
(excluding
bracket)
5.1 x 4.725 in.
12.95 x 12.0 cm
5.1 x 4.725
in.
12.95 x 12.0
cm
6.6 x 2.7 in.
16.5 x 6.9 cm
5.3 x 2.7 in.
13.5 x 6.9 cm
Operating Tem-
perature
32 - 131 deg. F
(0 - 55 deg. C)
32 - 131 deg.
F
(0 - 55 deg.
C)
32 - 131 deg. F
(0 - 55 deg. C)
32 - 131 deg. F
(0 - 55 deg. C)
MTBF
PRO/1000 PT Server Adapter:
117 years
PRO/1000 PT Dual Port Server
Adapter: 91 years
60 years
Intel® Gigabit ET Dual Port Server
Adapter: 81 years
Intel® Gigabit ET Quad Port
Server Adapter: 40 years
68 years
Available
Speeds
10/100/1000
auto-negotiate
1000 only 10/100/1000
auto-negotiate
10/100/1000
auto-negotiate
Duplex Modes
Full or half at 10/100 Mbps; full
only at 1000 Mbps
Full only Full or half at 10/100 Mbps; full only
at 1000 Mbps
Full or half at 10/100
Mbps; full only at 1000
Mbps
Standards Con-
formance
IEEE 802.1p
IEEE 802.1Q
IEEE 802.3ab
IEEE 802.3ac
IEEE 802.3ad
IEEE 802.3u
IEEE 802.3x
IEEE 802.3z
ACPI v1.0
PCI Express 1.0a
IEEE 802.1p
IEEE
802.1Q
IEEE
802.3ac
IEEE
802.3ad
IEEE 802.3x
IEEE 802.3z
ACPI v1.0
PCI Express
1.0a
IEEE 802.1p
IEEE 802.1Q
IEEE 802.3ab
IEEE 802.3ac
IEEE 802.3ad
IEEE 802.3u
IEEE 802.3x
IEEE 802.3z
ACPI v1.0
PCI Express 2.0
IEEE 802.1p
IEEE 802.1Q
IEEE 802.3ab
IEEE 802.3ac
IEEE 802.3ad
IEEE 802.3az
IEEE 802.3u
IEEE 802.3x
IEEE 802.3z
ACPI v1.0
PCI Express 2.0
Indicator Lights
PRO/1000 PT Server Adapter:
Link/Activity
10/100/1000 (Speed)
PRO/1000 PT Dual Port Server
Adapter:
Two per port:
Link/Activity and Identity
10/100/1000 (Speed)
Link/Activity
Two per port:
Link/Activity and Identity
10/100/1000 (Speed)
Two per port:
Activity and Speed
Regulatory and
Safety
Safety Compliance
l
UL 60950 Third Edition- CAN/CSA-C22.2 No.60950-00 (USA/Canada)
l
EN 60 950 (European Union)
l
IEC 60 950 (International)
EMC Compliance
l
FCC Part 15 - Radiated & Conducted Emissions (USA)
l
ICES-003 - Radiated & Conducted Emissions (Canada)
l
CISPR 22 - Radiated & Conducted Emissions (International)
l
EN55022-1998 - Radiated & Conducted Emissions (European Union)
l
EN55024 - 1998 - (Immunity) (European Union)

Intel Ethernet X520 10GbE Dual Port KX4 Mezz Specifications

General

Interface	KX4
Data Rate	10 Gbps
Form Factor	Mezzanine
Data Transfer Rate	10 Gbps
Product Type	Network Adapter
Controller	Intel 82599
PCIe Version	2.0
Virtualization	Yes
Operating Temperature	0°C to 55°C
Jumbo Frames	Supported
Ports	Dual Port
