115 Datasheet
Processor Pin and Signal Information
AR1 RSVD_NCTF
AR2 RSVD_NCTF
AR3 VSS GND
AR4 SB_DM[6] DDR3 O
AR5 SB_DQS#[6] DDR3 I/O
AR6 VSS GND
AR7 SB_DQS[7] DDR3 I/O
AR8 SB_DQS#[7] DDR3 I/O
AR9 VSS GND
AR10 SB_DQ[62] DDR3 I/O
AR11 SA_DQ[50] DDR3 I/O
AR12 VSS GND
AR13 SA_DQS[7] DDR3 I/O
AR14 SA_DQ[62] DDR3 I/O
AR15 VSS GND
AR16 VAXG REF
AR17 VSS GND
AR18 VAXG REF
AR19 VAXG REF
AR20 VSS GND
AR21 VAXG REF
AR22 VAXG_SENSE Analog O
AR23 VSS GND
AR24 VSS GND
AR25 GFX_VR_EN CMOS O
AR26 VSS GND
AR27 TDO CMOS O
AR28 VSS GND
AR29 TDI_M CMOS I
AR30 BCLK_ITP DIFF
CLK
O
AR31 VSS GND
AR32 RSVD
AR33 RSVD
AR34 VSS_NCTF
AR35 RSVD_NCTF
AT1 VSS_NCTF
Table 8-49.rPGA988A Processor Pin
List by Pin Number
Pin
Number
Pin Name
Buffer
Type
Dir.
AT2 RSVD_TP
AT3 RSVD_NCTF
AT4 SB_DQ[50] DDR3 I/O
AT5 SB_DQ[54] DDR3 I/O
AT6 SB_DQ[55] DDR3 I/O
AT7 SB_DQ[60] DDR3 I/O
AT8 SB_DM[7] DDR3 O
AT9 SB_DQ[59] DDR3 I/O
AT10 SB_DQ[63] DDR3 I/O
AT11 SA_DQ[54] DDR3 I/O
AT12 SA_DQ[60] DDR3 I/O
AT13 SA_DQS#[7] DDR3 I/O
AT14 SA_DQ[59] DDR3 I/O
AT15 PECI Async I/O
AT16 VAXG REF
AT17 VSS GND
AT18 VAXG REF
AT19 VAXG REF
AT20 VSS GND
AT21 VAXG REF
AT22 VSSAXG_SENS
E
Analog O
AT23 COMP3 Analog I
AT24 COMP2 Analog I
AT25 GFX_DPRSLPVR CMOS O
AT26 COMP0 Analog I
AT27 TRST# CMOS I
AT28 PRDY# Async
GTL
O
AT29 TDI CMOS I
AT30 BCLK_ITP# DIFF
CLK
O
AT31 RSVD
AT32 RSVD
AT33 RSVD_NCTF
AT34 RSVD_NCTF
AT35 VSS_NCTF
Table 8-49.rPGA988A Processor Pin
List by Pin Number
Pin
Number
Pin Name
Buffer
Type
Dir.
