Intel PENTIUM P6000 - DATASHEET 2010 - Page 126

126 Datasheet
Processor Pin and Signal Information
RSVD_NCTF A34
RSVD_NCTF AP1
RSVD_NCTF AP35
RSVD_NCTF AR1
RSVD_NCTF AR2
RSVD_NCTF AR35
RSVD_NCTF AT3
RSVD_NCTF AT33
RSVD_NCTF AT34
RSVD_NCTF B35
RSVD_NCTF C1
RSVD_NCTF C35
RSVD_TP AA1
RSVD_TP AA2
RSVD_TP AA4
RSVD_TP AA5
RSVD_TP AD2
RSVD_TP AD3
RSVD_TP AD5
RSVD_TP AD7
RSVD_TP AD9
RSVD_TP AE3
RSVD_TP AE5
RSVD_TP AG7
RSVD_TP AJ12
RSVD_TP AJ13
RSVD_TP AK26
RSVD_TP AL26
RSVD_TP AT2
RSVD_TP E15
RSVD_TP F15
RSVD_TP H16
RSVD_TP N2
RSVD_TP N3
RSVD_TP R8
RSVD_TP R9
Table 8-50.rPGA988A Processor Pin
List by Pin Name
Pin Name
Pin
Number
Buffer
Type
Dir.
RSVD_TP V4
RSVD_TP V5
RSVD_TP W2
RSVD_TP W3
SA_BS[0] AC3 DDR3 O
SA_BS[1] AB2 DDR3 O
SA_BS[2] U7 DDR3 O
SA_CAS# AE1 DDR3 O
SA_CK[0] AA6 DDR3 O
SA_CK[1] Y6 DDR3 O
SA_CK#[0] AA7 DDR3 O
SA_CK#[1] Y5 DDR3 O
SA_CKE[0] P7 DDR3 O
SA_CKE[1] P6 DDR3 O
SA_CS#[0] AE2 DDR3 O
SA_CS#[1] AE8 DDR3 O
SA_DM[0] B9 DDR3 O
SA_DM[1] D7 DDR3 O
SA_DM[2] H7 DDR3 O
SA_DM[3] M7 DDR3 O
SA_DM[4] AG6 DDR3 O
SA_DM[5] AM7 DDR3 O
SA_DM[6] AN10 DDR3 O
SA_DM[7] AN13 DDR3 O
SA_DQ[0] A10 DDR3 I/O
SA_DQ[1] C10 DDR3 I/O
SA_DQ[2] C7 DDR3 I/O
SA_DQ[3] A7 DDR3 I/O
SA_DQ[4] B10 DDR3 I/O
SA_DQ[5] D10 DDR3 I/O
SA_DQ[6] E10 DDR3 I/O
SA_DQ[7] A8 DDR3 I/O
SA_DQ[8] D8 DDR3 I/O
SA_DQ[9] F10 DDR3 I/O
SA_DQ[10] E6 DDR3 I/O
SA_DQ[11] F7 DDR3 I/O
Table 8-50.rPGA988A Processor Pin
List by Pin Name
Pin Name
Pin
Number
Buffer
Type
Dir.
