Intel PENTIUM P6000 - DATASHEET 2010 - Page 171

Datasheet 171
Processor Pin and Signal Information
BT33 SB_MA[5] DDR3 O
BT34 SB_MA[0] DDR3 O
BT36 SA_MA[0] DDR3 O
BT38 SA_BS[0] DDR3 O
BT40 SB_RAS# DDR3 O
BT41 SB_WE# DDR3 O
BT43 SB_CS#[1] DDR3 O
BT45 SB_MA[13] DDR3 O
BT47 SB_DQ[36] DDR3 I/O
BT48 SB_DQ[32] DDR3 I/O
BT50 SB_DQS[4] DDR3 I/O
BT52 SB_DQS#[4] DDR3 I/O
BT54 SB_DQ[39] DDR3 I/O
BT55 SB_DQ[45] DDR3 I/O
BT57 SB_DQ[43] DDR3 I/O
BT59 SB_DQ[42] DDR3 I/O
BT61 SB_DQ[53] DDR3 I/O
BT68 VSS GND
BT69 DC_TEST_BT69
BT71 DC_TEST_BT71
BU7 VSS GND
BU9 SB_DQ[14] DDR3 I/O
BU11 VSS GND
BU12 SB_DQS#[2] DDR3 I/O
BU14 VSS GND
BU16 SB_DQ[23] DDR3 I/O
BU18 VSS GND
BU19 SB_DQ[25] DDR3 I/O
BU21 VSS GND
BU23 SB_MA[15] DDR3 O
BU25 VSS GND
BU26 SB_MA[11] DDR3 O
BU28 VDDQ REF
BU30 SB_MA[3] DDR3 O
BU32 VSS GND
BU33 SB_CK[0] DDR3 O
Table 8-52.BGA1288 Processor Ball
List by Ball Number
(Sheet 25 of 37)
Pin # Pin Name
Buffer
Type
Dir
BU35 VDDQ REF
BU37 VSS GND
BU39 SB_CK#[1] DDR3 O
BU40 VDDQ REF
BU42 SB_MA[10] DDR3 O
BU44 VSS GND
BU46 SB_CAS# DDR3 O
BU48 VSS GND
BU49 SB_ODT[1] DDR3 O
BU51 VSS GND
BU53 SB_DQ[41] DDR3 I/O
BU55 VSS GND
BU56 SB_DQS[5] DDR3 I/O
BU58 VSS GND
BU60 SB_DQ[46] DDR3 I/O
BU62 VSS GND
BU63 SB_DQS#[6] DDR3 I/O
BU65 SB_DM[6] DDR3 O
BV1 DC_TEST_BV1
BV3 DC_TEST_BV3
BV5 DC_TEST_BV5
BV6 RSVD_NCTF
BV8 RSVD_NCTF
BV10 SB_DQ[15] DDR3 I/O
BV12 SB_DQ[20] DDR3 I/O
BV13 SB_DQS[2] DDR3 I/O
BV15 SB_DQ[19] DDR3 I/O
BV17 SB_DQ[22] DDR3 I/O
BV19 SB_DQ[29] DDR3 I/O
BV20 SB_DQ[30] DDR3 I/O
BV22 SB_DQ[26] DDR3 I/O
BV24 SB_BS[2] DDR3 O
BV26 SB_MA[14] DDR3 O
BV27 SB_MA[8] DDR3 O
BV29 SB_MA[2] DDR3 O
BV31 SB_MA[4] DDR3 O
Table 8-52.BGA1288 Processor Ball
List by Ball Number
(Sheet 26 of 37)
Pin # Pin Name
Buffer
Type
Dir
