Intel PENTIUM P6000 - DATASHEET 2010 - Page 174

174 Datasheet
Processor Pin and Signal Information
J9 VSS GND
J20 PEG_TX#[15] PCIe O
J21 PEG_CLK# DIFF
CLK
I
J28 PEG_RX[4] PCIe I
J30 PEG_TX[8] PCIe O
J38 PEG_RX[1] PCIe I
J40 VSS GND
J47 VSS GND
J48 VSS GND
J55 VCC REF
J57 VSS GND
J62 BPM#[2] GTL I/O
J64 BPM#[5] GTL I/O
J65 VSS GND
J67 BPM#[1] GTL I/O
J69 BPM#[0] GTL I/O
J70 BCLK_ITP # DIFF
CLK
O
K1 FDI_TX[0] FDI O
K4 VSS GND
K6 VSS GND
K8 DMI_RX#[2] DMI I
K9 DMI_RX[2] DMI I
K11 VSS GND
K15 DMI_TX#[1] DMI O
K17 VSS GND
K24 PEG_RX[6] PCIe I
K25 VSS GND
K32 VSS GND
K34 VSS GND
K36 VSS GND
K43 VSS GND
K44 VCC REF
K51 VCC REF
K53 VSS GND
Table 8-52.BGA1288 Processor Ball
List by Ball Number
(Sheet 31 of 37)
Pin # Pin Name
Buffer
Type
Dir
K60 VCC REF
K62 BPM#[4] GTL I/O
K64 VSS GND
K65 BPM#[3] GTL I/O
K69 BPM#[6] GTL I/O
K71 BCLK_ITP DIFF
CLK
O
L2 FDI_TX#[0] FDI O
L13 VSS GND
L20 PEG_TX[15] PCIe O
L21 PEG_CLK Diff CLK I
L28 PEG_TX#[11] PCIe O
L30 PEG_TX#[8] PCIe O
L38 PEG_TX#[1] PCIe O
L40 PEG_TX[0] PCIe O
L47 VSS GND
L48 VSS GND
L55 VCC REF
L57 VSS GND
L70 VSS GND
M1 VSS GND
M4 FDI_TX#[2] FDI O
M15 DMI_TX[1] DMI O
M17 PM_SYNC CMOS I
M24 PEG_TX#[13] PCIe O
M25 PEG_TX[12] PCIe O
M32 PEG_TX#[2] PCIe O
M34 PEG_RX[3] PCIe I
M36 VSS GND
M42 VSS GND
M44 VCC REF
M51 VCC REF
M53 VSS GND
M60 VCC REF
M69 BPM#[7] GTL I/O
Table 8-52.BGA1288 Processor Ball
List by Ball Number
(Sheet 32 of 37)
Pin # Pin Name
Buffer
Type
Dir
