Intel® Thermal/Mechanical Reference Design Information
Thermal and Mechanical Design Guidelines 43
5 Intel
®
Thermal/Mechanical
Reference Design Information
5.1 ATX Reference Design Requirements
This chapter will document the requirements for an active air-cooled design, with a
fan installed at the top of the heatsink. The thermal technology required for the
processor.
The Intel
®
Core™2 Extreme quad-core processor QX6000 series at the
775_VR_CONFIG_05B and Intel
®
Core™2 Extreme processor QX9000 series require a
thermal solution equivalent to the RCFH-4 reference design, see Figure 10 for an
expl
oded view of this reference design.
Figure 10. Intel
®
RCFH-4 Reference Design - Exploded View
Wire Guard
Fan Assy.
Extrusion
Clip
Fastener
Wire Guard
Fan Assy.
Extrusion
Clip
Fastener
Note: Development vendor information for the Intel
®
RCFH-4 Reference Solution is provided
in
0.
