Intel® Server S2600WF Product Family Configuration Guide
105
System
Configuration
NVMe Drive
Support
Onboard PCIe OCuLink to
Drive Bay Module (BP) #1
Cable Kits
PCIe Retimer Card Option on
Riser #1
(NOT SUPPORTED
1
)
PCIe Retimer Card Option on
Riser #2
PCIe Retimer Card to
Drive Bay Module (BP) #3
Cable Kits
Cable
Routing
Drive Bay #3
R2224WF…
Up to Eight
2.5” NVMe
SSDs
PCIe SSD 0 (CR)  BP 0 (CV)
800mm – AXXCBL800CVCR
PCIe SSD 1 (CR)  BP 1 (CV)
800mm – AXXCBL800CVCR
PCIe SSD 2 (CR)  BP 2 (CV)
600mm – AXXCBL600CVCR
PCIe SSD 3 (CR)  BP 3 (CV)
600mm – AXXCBL600CVCR
PCIe SSD 0 (CR)  BP 4 (CV)
800mm – AXXCBL800CVCR
PCIe SSD 1 (CR)  BP 5 (CV)
800mm – AXXCBL800CVCR
PCIe SSD 2 (CR)  BP 6 (CV)
530mm – AXXCBL530CVCR
PCIe SSD 3 (CR)  BP 7 (CV)
530mm – AXXCBL530CVCR
All cables routed Right
4-port PCIe Retimer Add-in
Card
AXXP3RTX16040
top PCIe slot #1
Retimer  BP ports 0-3
or
Retimer  BP ports 4-7
A2U4PRTCXCXK
Right
1
PCIe retimer card installed to Riser #1 is not supported.
