Intel® Server S2600WF Product Family Configuration Guide
34
Feature
Description
Riser Card Support
Support for three riser cards:
• Riser #1 – PCIe* 3.0 x24 - up to 3 PCIe slots
• Riser #2 – PCIe* 3.0 x24 - up to 3 PCIe slots
• Riser #3 – PCIe* 3.0 x16 – up to 2 PCIe slots – Low profile cards only (optional)
With three riser cards installed, up to eight possible add-in cards can be supported:
• (4) full height/half-length + (2) full height/half-length add-in cards via Risers #1 and #2
• (2) low profile add in cards via riser #3 (option)
Power Supply Options
The server system can have up to two power supply modules installed, providing support for the following power configurations:
1+0, 1+1 redundant power, and 2+0 combined power.
• (3) power supply options:
o AC 1100 W Platinum
o AC 1300 W Titanium
o DC 750 W Gold
Drive Bay Options
• Hot-swap backplane options:
o 8 x 3.5” SAS/ SATA
o 8 x 2.5” combo backplane – SAS/SATA/NVMe*
o 8 x 2.5” Dual Port SAS
o 12 x 3.5” SAS/ SATA (supports up to 2 NVMe drives)
Note: All available backplane options have support for SAS 3.0 (12 Gb/sec).
• Storage bay options:
o 8 x 3.5” SAS/SATA hot swap drive bays
o 12 x 3.5” SAS/SATA hot swap drive bays (supports up to 2 NVMe drives)
o 8 x 2.5” SAS/SATA/NVMe hot swap drive bays
o 16 x 2.5” SAS/SATA/NVMe hot swap drive bays
o 24 x 2.5” SAS/SATA/NVMe swap drive bays
o 2 x 2.5” SATA SSD back of chassis hot-swap drive bays (accessory option)
o 2 x internal fixed mount 2.5” SSDs (all system models)
Supported Rack Mount Kit Accessory
Options
• AXXELVRAIL – Enhanced value rack mount rail kit – 424 mm max travel length, 59 kg max supported weight
• AXXFULLRAIL – 2U premium rail with CMA support – 800 mm max travel length, 45 kg max supported weight
• AXXSHRTRAIL – 2U premium rail without CMA support – 788 mm max travel length, 45 kg max supported weight
• AXX2POSTBRCKT – Two post fixed mount bracket kit
• AXXCMA2– Cable management arm (supported with AXXFULLRAIL only)
