Intel® Server Board S2600CO Family TPS On-board Connector/Header Overview
Revision 1.0
Intel order number G42278-002
95
The server board includes two red 10-pin IEEE 1394b connectors. On the server board, this
header is labeled FRONT_1394B_0 and FRONT_1394B_1. The header has the following pin-
out.
Table 55. IEEE 1394b Connector pin out
Pin
Signal Name
Pin
Signal Name
1
GND
3
+12V (Fused)
4
+12V (Fused)
5
TPB-
6
TPB+
7
TPB_REF
8
TPA_REF
9
TPA_
10
TPA+
