Intel® Server Board S2600CO Family TPS Product Overview
Revision 1.0 3
Intel order number G42278-002
2. Product Overview
The Intel
®
Server Board S2600CO is a monolithic printed circuit board (PCB) assembly with
features designed to support the pedestal server markets. It has two board SKUs, namely
S2600CO4 and S2600COE. These server boards are designed to support the Intel
®
Xeon
®
Processor E5-2600 product family. Previous generation Intel
®
Xeon
®
processors are not
supported. Many of the features and functions of these two SKUs are common. A board will be
identified by name when a described feature or function is unique to it.
Table 1. Intel
®
Server Board S2600CO Family Feature Set
Feature
Description
Processor Support
 Two LGA 2011 (Socket R) processor sockets
 S2600CO4 - Support for one or two Intel
®
Xeon
®
Processor(s) E5-2600 product with
a Thermal Design Power (TDP) of up to 135W.
 S2600COE - Support for one or two Intel
®
Xeon
®
Processor(s) E5-2600 product
family with a Thermal Design Power (TDP) of up to 150W with possible
configuration limits.
Memory
 16 DIMM slots – 2 DIMM slots/channel – 4 memory channels per processor
 Channels A, B, C, D, E, F, G and H
 Support for Registered DDR3 Memory (RDIMM), LV-RDIMM, Unbuffered DDR3
memory ((UDIMM) with ECC and Load Reduced DDR3 memory (LR-DIMM)
 Memory DDR3 data transfer rate of 800, 1066, and 1333 MT/s and1600 MT/s
 DDR3 standard I/O voltage of 1.5V and DDR3 Low Voltage of 1.35V
Chipset
Intel
®
C600-A chipset with support for optional Storage Option Select keys
Rear I/O connections
 One DB15 Video VGA connector
 One DB9 Serial connector
 Four USB2.0 connectors
 Four RJ-45 Network Interface Connectors supporting 10/100/1000Mb
Internal I/O
connectors/headers
 One 2x5 pin connector providing front panel support for two USB ports
 One internal type A USB 2.0 connector
 One internal low-profile 2mm USB port for USB Solid State Drive
 One 2x15 pin SSI-EEB compliant front panel connector
 One DH-10 Serial Port B connector
 Two internal IEEE 1394b connectors (Intel
®
Server Board S2600COE only.)
Cooling Fan Support
 Two 4-pin managed CPU fan headers
 Six 6-pin managed system fan headers
 One 4-pin managed rear system fan header
 One 4-pin I2C header that is intended to be used for third party fan control circuits
using a Maxim 72408 controller. (Intel
®
Server Board S2600CO4 only.)
