Appendix B: Compatiable Intel® Server Chassis Intel® Server Board S2600CO Family TPS
Revision 1.0
Intel order number G42278-002
118
13. P4216XXMHEN – one 550-W non-redundant fixed PSU, two non-redundant fixed
120x38mm system fans and up to sixteen 2.5" hot-swap hard drives.
14. P4308XXMHGR – two 750-W redundant hot-swap PSU, two non-redundant fixed
120x38mm system fans and up to eight 3.5" hot-swap hard drives.
15. P4308XXMHGN – one 750-W hot-swap PSU, two non-redundant fixed 120x38mm
system fans and up to eight 3.5" hot-swap hard drives.
16. P4308XXMFGR – two 750-W redundant hot-swap PSU, two non-redundant fixed
120x38mm system fans and up to eight 3.5" fixed hard drives.
17. P4308XXMHDR – two 460-W redundant hot-swap PSU, two non-redundant fixed
120x38mm system fans and up to eight 3.5" hot-swap hard drives.
18. P4308XXMHDN – one 460-W hot-swap PSU, two non-redundant fixed 120x38mm
system fans and up to eight 3.5" hot-swap hard drives.
19. P4308XXMFDR – two 460-W redundant hot-swap PSU, two non-redundant fixed
120x38mm system fans and up to eight 3.5" fixed hard drives.
20. P4308XXMFDN – one 460-W hot-swap PSU, two non-redundant fixed 120x38mm
system fans and up to eight 3.5" fixed hard drives.
21. P4304XXMHEN – one 550-W non-redundant fixed PSU, two non-redundant fixed
120x38mm system fans and up to four 3.5" hot-swap hard drives.
The following table summarizes the features for all chassis combinations:
Table 69. Intel
®
Server Chassis P4000M family Features
Configuration
P4308XXMFEN
P4308XXMHEN
P4308XXMFGN
P4308XXMHGC
P4308XXMHJC
Intel
®
Server
Board
Support
 Intel
®
Server Board S2600CP
 Intel
®
Server Board S2600CO
 Intel
®
Server Board S2400SC
 Intel
®
Server Board S2400GP
Power
550W non-redundant fixed
power supply
One 750W hot-
swap power
supply with
high current
PDB
Two 750W
redundant
hot-swap
power supply
with high
current PDB
Two 1200W redundant hot-
swap power supply with high
current PDB
System
Cooling
Two 120x38mm non-redundant fans
Five 80x38mm redundant hot swap fans
Peripherals
Bays
Three (3) half height 5-1/4" bays for optical devices.
Drive Bays
Includes one
fixed drive
bay. Supports
up to eight 3.5"
fixed hard
drives
Includes one
8x3.5" hot-
swap hard
drive cage.
Supports up to
eight 3.5” hot-
swap hard
drives.
Includes one
fixed drive bay.
Supports up to
eight 3.5" fixed
hard
Includes one 8x3.5" hot-swap hard drive cage.
Supports up to eight 3.5” hot-swap hard drives.
Expansion
Slots
Support up to six (6) full height, full length PCI form factor cards mechanically.
