Intel S2600CO Family User Manual

Intel® Server Board S2600CO Family TPS Appendix B: Compatiable Intel® Server Chassis
Revision 1.0
Intel order number G42278-002
119
Configuration
P4308XXMFEN
P4308XXMHEN
P4308XXMFGN
P4308XXMHGC
P4308XXMHJC
Front Panel
Power Button with LED, Reset Button, NMI Button, ID Button with LED, Four NIC LEDs, Hard drive
activity LED, System status LED, two USB ports, Optional front serial port/VGA port
Appearance
Color: Cosmetic black (GE 701 or equivalent), service Intel blue, hot swap Intel green.
Support for Intel standard front panel or LCD
Dimensions
Pedestal
17.24 in (438 mm) x 6.81 in (173mm) x 25 in (612 mm) (Height X Width X Depth)
Optional
Accessory
Kits
Zephyr flash storage, RMM4-lite modules, TPM module, dedicated NIC module, Expander Card module,
Configuration
P4208XXMHEN
P4208XXMHDR
P4208XXMHGR
P4208XXMHGC
P4216XXMHJC
Intel
®
Server
Board
Support
 Intel
®
Server Board S2600CP
 Intel
®
Server Board S2600CO
 Intel
®
Server Board S2400SC
 Intel
®
Server Board S2400GP
Power
550W non-
redundant
fixed power
supply
Two 460W
redundant hot-
swap power
supply with
low current
PDB
Two 750W redundant hot-swap
power supply with high current
PDB
Two 1200W redundant hot-
swap power supply with high
current PDB
System
Cooling
Two 120x38mm non-redundant fans
Five 80x38mm redundant hot swap fans
Peripherals
Bays
Three (3) half height 5-1/4" bays for optical devices.
Drive Bays
Include one 8x2.5” hot-swap hard drive cage. Supports up to eight
2.5” hot-swap hard drives.
Include two 8x2.5” hot-swap
hard drive cage. Supports up to
sixteen 2.5” hot-swap hard
drives.
Expansion
Slots
Support up to six (6) full height, full length PCI form factor cards mechanically
Front Panel
Power Button with LED, Reset Button, NMI Button, ID Button with LED, Four NIC LEDs, Hard drive
activity LED, System status LED, two USB ports, Optional front serial port/VGA port
Appearance
Color: Cosmetic black (GE 701 or equivalent), service Intel blue, hot swap Intel green.
Support for Intel standard front panel or LCD
Dimensions
Pedestal
17.24 in (438 mm) x 6.81 in (173mm) x 25 in (612 mm) (Height X Width X Depth)
Optional
Accessory
Kits
Zephyr flash storage, RMM4-lite modules, TPM module, dedicated NIC module, Expander Card module
Configuration
P4216XXMHGC
P4216XXMHGR
P4308XXMHGR
P4308XXMFGR
P4308XXMHGN
Intel
®
Server
Board
Support
 Intel
®
Server Board S2600CP
 Intel
®
Server Board S2600CO
 Intel
®
Server Board S2400SC
 Intel
®
Server Board S2400GP
Power
Two 750W redundant hot-swap power supply with high current PDB
One 750W hot-swap power
supply with high current PDB
System
Cooling
Five 80x38mm
redundant hot
swap fans
Two 120x38mm non-redundant fans
Peripherals
Bays
Three (3) half height 5-1/4" bays for optical devices.
