Intel® Server Board S2600CO Family TPS Platform Management Functional Overview
Revision 1.0 77
Intel order number G42278-002
Support for multiple debug files. The platform debug feature provides the ability to save
data to 2 separate files that are encrypted with different passwords.
o File #1 is strictly for viewing by Intel engineering and may contain BMC log
messages (a.k.a. syslog) and other debug data that Intel FW developers deem
useful in addition to the data specified in this document.
o File #2 can be viewed by Intel partners who have signed an NDA with Intel and
its contents are restricted to specific data items specified in this with the
exception of the BMC syslog messages and power supply “black box” data.
6.10.15.1 Output Data Format
The diagnostic feature shall output a password-protected compressed HTML file containing
specific BMC and system information. This file is not intended for end-customer usage, this file
is for customer support and engineering only.
6.10.15.2 Output Data Availability
The diagnostic data shall be available on-demand from the embedded web server, KCS, or IPMI
over LAN commands.
6.10.15.3 Output Data Categories
The following tables list the data to be provided in the diagnostic output. For items in Table 20,
this data is collected on detection of CATERR, ERR2, PERR, SERR, and SMI timeout. The data
in Table 21 is accumulated for the three most recent overall errors.
Table 20. Diagnostic Data.
Human-readable SEL listing
Human-readable sensor listing
POST codes for the two most recent boots
SMBIOS table for the current boot
256 bytes of PCI config data for each PCI device
Table 21. Additional Diagnostics on Error.
First 256 bytes of PCI config data for each PCI
device
