Intel S2600CO Family

Intel® Server Board S2600CO Family TPS Product Overview
Revision 1.0 9
Intel order number G42278-002
Callout
Description
Callout
Description
A
Serial Port A
E
NIC Port 3 and 4
B
Video
F
Diagnostics LED’s
C
NIC Port 1, USB Port 0 (top) and 1
(bottom)
G
ID LED
D
NIC Port 2, USB Port 2 (top) and 3
(bottom)
H
Status LED
Figure 4. Rear I/O Layout
