Product Overview Intel® Server Board S2600CO Family TPS
4 Revision 1.0
Intel order number G42278-002
Feature
Description
Add-in Card Slots
 Support up to six expansion slots
 Slot 1: PCIe Gen II x4 electrical with x8 physical connector, routed from Intel
®
C600
Chipset, support half-length card
 Slot 2: PCIe Gen III x16 electrical with x16 physical connector, routed from CPU1,
support full length card
 Slot 3: PCIe Gen III x16 electrical with x16 physical connector, routed from CPU2,
support full length, double width card
 Slot 4: PCIe Gen III x8 electrical with x8 connector, routed from CPU2, support full
length card; support Intel designed SAS RAID on Card (ROC) Module (PCIe slot
form factor)
 Slot 5: PCIe Gen III x16 electrical with x16 connector, routed from CPU1, support
full length, double width card
 Slot 6: PCIe Gen III x16 electrical with x16 connector, routed from CPU2, support
half-length card, Intel designed PCIe riser card
Storage
 One low-profile eUSB 2x5 pin connector to support 2mm low-profile eUSB solid
state devices
 Two AHCI SATA connectors capable of supporting up to 6Gb/sec
 AHCI SATA 0 supports high profile, vertical SATA DOM with onboard power.
 Eight SCU SAS/SATA connectors capable of supporting up to 3Gb/sec
 Intel SAS ROC module support (Optional, PCIe slot form factor)
 Intel
®
RAID C600 Upgrade Key support providing optional expanded SAS/SATA
RAID capabilities
RAID Support
 Intel
®
RSTe SW RAID 0/1/10/5
 LSI SW RAID 0/1/10
Video Support
Integrated Matrox G200 2D Video Graphics controller
LAN
Four Gigabit through Intel
®
I350-AM Quad 10/100/1000 integrated GbE MAC and PHY
controller
Security
Trusted Platform Module (Accessory Option)
Server Management
 Integrated Baseboard Management Controller, IPMI 2.0 compliant
 Support for Intel
®
Server Management Software
 Intel
®
Remote Management Module 4 support (Accessory Option)
 Intel
®
Remote Management Module 4 Lite support (Accessory Option)
Form Factor
SSI EEB (12”x13”)
Compatible Intel
®
Server
Chassis
Intel
®
Server Chassis P4000M family

Intel S2600CO Family Specifications

General

Brand	Intel
Model	S2600CO Family
Category	Server Board
Language	English
