Appendix C: Integrated BMC Sensor Tables Intel® Server Board S2600CO Family TPS
Revision 1.0
Intel order number G42278-002
130
Full Sensor Name
(Sensor name in SDR)
Sensor
#
Platform
Applicability
Sensor Type
Event /
Reading
Type
Event Offset Triggers
Contrib. To
System Status
Assert
/ De-
assert
Readable
Value /
Offsets
Event
Data
Rearm
Stand-
by
Processor 1 Thermal Margin
(P1 Therm Margin)
74h
All
Temperature
01h
Threshold
01h
-
-
-
Analog
R, T
A
–
Processor 2 Thermal Margin
(P2 Therm Margin)
75h
All
Temperature
01h
Threshold
01h
-
-
-
Analog
R, T
A
–
Processor 1 Thermal
Control %
(P1 Therm Ctrl %)
78h
All
Temperature
01h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog
Trig Offset
A
–
Processor 2 Thermal
Control %
(P2 Therm Ctrl %)
79h
All
Temperature
01h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog
Trig Offset
A
–
Processor 1 ERR2 Timeout
(P1 ERR2)
7Ch
All
Processor
07h
Digital
Discrete
03h
01 – State Asserted
fatal
As
and
De
–
Trig Offset
A
–
Processor 2 ERR2 Timeout
(P2 ERR2)
7Dh
All
Processor
07h
Digital
Discrete
03h
01 – State Asserted
fatal
As
and
De
–
Trig Offset
A
–
Catastrophic Error
(CATERR)
80h
All
Processor
07h
Digital
Discrete
03h
01 – State Asserted
fatal
As
and
De
–
Trig Offset
M
–
Processor0 MSID Mismatch
(P0 MSID Mismatch)
81h
All
Processor
07h
Digital
Discrete
03h
01 – State Asserted
fatal
As
and
De
–
Trig Offset
M
–
Processor Population Fault
(CPU Missing)
82h
All
Processor
07h
Digital
Discrete
03h
01 – State Asserted
Fatal
As
and
De
–
Trig Offset
M
–
Processor1 MSID Mismatch
(P1 MSID Mismatch)
87h
All
Processor
07h
Digital
Discrete
03h
01 – State Asserted
fatal
As
and
De
–
Trig Offset
M
–
Processor 1 VRD
Temperature
(P1 VRD Hot)
90h
All
Temperature
01h
Digital
Discrete
05h
01 - Limit exceeded
Non-fatal
As
and
De
–
Trig Offset
M
–
