Intel S2600CO Family User Manual

Intel® Server Board S2600CO Family TPS Appendix D: Intel® Server Board S2600CO Family Specific Sensors
Revision 1.0
Intel order number G42278-002
137
Chassis
Fan Domain
Major Components Cooled
(Temperature sensor number)
Fans
(Sensor number)
 HSBP 1 Temp(29h)
 HSBP 2 Temp(2Ah)
 Exit Air Temp(2Eh)
 P1 Therm Margin (74h)
 P2 Therm Margin (75h)
 DIMM Thrm Mrgn 1 (B0h)
 DIMM Thrm Mrgn 2 (B1h)
 DIMM Thrm Mrgn 3(B2h)
 DIMM Thrm Mrgn 4 (B3h)
6
 P1 MEM01 VRD Hot (94h)
Processor 1 Fan(36h)
7
 P1 MEM23 VRD Hot (95h)
 BB P2 VR Temp (24h)
Processor 2 Fan(37h)
P4208/
P4308/
P4216 (UPM with
redundant fan 4U)
0
 SSB Temp (22h)
 BB BMC Temp (23h)
 BB MEM VR Temp (25h)
 HSBP 1 Temp (29h)
 HSBP 2 Temp (2Ah)
 Exit Air Temp (2Eh)
 LAN NIC Temp (2Fh)
System Fan 1(30h)
1
 SSB Temp(22h)
 BB BMC Temp (23h)
 BB MEM VR Temp (25h)
 HSBP 1 Temp (29h)
 HSBP 2 Temp (2Ah)
 Exit Air Temp (2Eh)
 LAN NIC Temp (2Fh)
 P1 Therm Margin (74h)
 P2 Therm Margin (75h)
 DIMM Thrm Mrgn 2 (B1h)
 DIMM Thrm Mrgn 3 (B2h)
System Fan 2(31h)
2
 BB P2 VR Temp (24h)
 BB MEM VR Temp (25h)
 HSBP 1 Temp (29h)
 HSBP 2 Temp (2Ah)
 Exit Air Temp (2Eh)
 P1 Therm Margin (74h)
 P2 Therm Margin (75h)
 DIMM Thrm Mrgn 1(B0h)
 DIMM Thrm Mrgn 2(B1h)
 DIMM Thrm Mrgn 3(B2h)
 DIMM Thrm Mrgn 4(B3h)
System Fan 3(32h)
3
 BB P2 VR Temp(24h)
 BB MEM VR Temp(25h)
 HSBP 1 Temp(29h)
 HSBP 2 Temp(2Ah)
 Exit Air Temp(2Eh)
System Fan 4(33h)
