Appendix C: Integrated BMC Sensor Tables Intel® Server Board S2600CO Family TPS
Revision 1.4
Intel order number G42278-004
126
Full Sensor Name
(Sensor name in SDR)
Sensor
#
Platform
Applicability
Sensor Type
Event/
Reading
Type
Event Offset Triggers Contrib. To
System Status
Assert/
De-
assert
Readable
Value/
Offsets
Event
Data
Rearm
Stand-
by
Hot-swap Backplane 3
Temperature
(HSBP 3 Temp)
2Bh
Chassis-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
PCI Riser 2 Temperature
(PCI Riser 2 Temp)
2Ch
Platform-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
SAS Module Temperature
(SAS Mod Temp)
2Dh
Platform-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Exit Air Temperature
(Exit Air Temp)
2Eh
Chassis and
Platform
Specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Network Interface Controller
Temperature
(LAN NIC Temp)
2Fh All
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Fan Tachometer Sensors
(Chassis specific
sensor names)
30h–
3Fh
Chassis and
Platform
Specific
Fan
04h
Threshold
01h
[l] [c,nc]
nc =
Degraded
c = Non-
fatal
Note2
As
and
De
Analog R, T M -
Fan Present Sensors
(Fan x Present)
40h–
4Fh
Chassis and
Platform
Specific
Fan
04h
Generic
08h
01 - Device inserted OK
As
and
De
-
Triggered
Offset
Auto
-
Power Supply 1 Status
(PS1 Status)
50h
Chassis-
specific
Power
Supply
08h
Sensor
Specific
6Fh
00 - Presence OK
As
and
De
– Trig Offset A X
01 - Failure Degraded
02 – Predictive Failure Degraded
03 - A/C lost Degraded
06 – Configuration
error
OK
Power Supply 2 Status
(PS2 Status)
51h
Chassis-
specific
Power
Supply
08h
Sensor
Specific
6Fh
00 - Presence OK
As
and
De
– Trig Offset A X
01 - Failure Degraded
02 – Predictive Failure Degraded
03 - A/C lost Degraded
