Intel® Server Board S2600CO Family TPS Appendix C: Integrated BMC Sensor Tables
Revision 1.4
Intel order number G42278-004
127
Full Sensor Name
(Sensor name in SDR)
Sensor
#
Platform
Applicability
Sensor Type Event/
Reading
Type
Event Offset Triggers Contrib. To
System Status
Assert/
De-
assert
Readable
Value/
Offsets
Event
Data
Rearm Stand-
by
06 – Configuration
error
OK
Power Supply 1
AC Power Input
(PS1 Power In)
54h
Chassis-
specific
Other Units
0Bh
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Power Supply 2
AC Power Input
(PS2 Power In)
55h
Chassis-
specific
Other Units
0Bh
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Power Supply 1 +12V % of
Maximum Current Output
(PS1 Curr Out %)
58h
Chassis-
specific
Current
03h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Power Supply 2 +12V % of
Maximum Current Output
(PS2 Curr Out %)
59h
Chassis-
specific
Current
03h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Power Supply 1 Temperature
(PS1 Temperature)
5Ch
Chassis-
specific
Temperature
01h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Power Supply 2 Temperature
(PS2 Temperature)
5Dh
Chassis-
specific
Temperature
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Hard Disk Drive 16 - 24
Status
(HDD 16 - 24 Status)
60h
–
68h
Chassis-
specific
Drive Slot
0Dh
Sensor
Specific
6Fh
00 - Drive Presence OK
As
and
De
– Trig Offset A X
01- Drive Fault Degraded
07 - Rebuild/Remap in
progress
Degraded
Processor 1 Status
(P1 Status)
70h All
Processor
07h
Sensor
Specific
6Fh
01 - Thermal trip Fatal
As
and
De
– Trig Offset M X
07 - Presence OK
Processor 2 Status
(P2 Status)
71h All
Processor
07h
Sensor
Specific
6Fh
01 - Thermal trip Fatal
As
and
De
– Trig Offset M X
07 - Presence OK
