Intel® Server Board S2600CO Family TPS Appendix C: Integrated BMC Sensor Tables
Revision 1.4
Intel order number G42278-004
129
Full Sensor Name
(Sensor name in SDR)
Sensor
#
Platform
Applicability
Sensor Type Event/
Reading
Type
Event Offset Triggers Contrib. To
System Status
Assert/
De-
assert
Readable
Value/
Offsets
Event
Data
Rearm Stand-
by
Processor 2 VRD
Temperature
(P2 VRD Hot)
91h All
Temperature
01h
Digital
Discrete
05h
01 - Limit exceeded Non-fatal
As
and
De
– Trig Offset M –
Processor 1 Memory VRD
Hot 0-1
(P1 Mem01 VRD Hot)
94h All
Temperature
01h
Digital
Discrete
05h
01 - Limit exceeded Non-fatal
As
and
De
– Trig Offset A –
Processor 1 Memory VRD
Hot 2-3
(P1 Mem23 VRD Hot)
95h All
Temperature
01h
Digital
Discrete
05h
01 - Limit exceeded Non-fatal
As
and
De
– Trig Offset A –
Processor 2 Memory VRD
Hot 0-1
(P2 Mem01 VRD Hot)
96h All
Temperature
01h
Digital
Discrete
05h
01 - Limit exceeded Non-fatal
As
and
De
– Trig Offset A –
Processor 2 Memory VRD
Hot 2-3
(P2 Mem23 VRD Hot)
97h All
Temperature
01h
Digital
Discrete
05h
01 - Limit exceeded Non-fatal
As
and
De
– Trig Offset A –
Power Supply 1 Fan
Tachometer 1
(PS1 Fan Tach 1)
A0h
Chassis-
specific
Fan
04h
Generic –
digital
discrete
01 – State Asserted Non-fatal
As
and
De
- Trig Offset M -
Power Supply 1 Fan
Tachometer 2
(PS1 Fan Tach 2)
A1h
Chassis-
specific
Fan
04h
Generic –
digital
discrete
01 – State Asserted Non-fatal
As
and
De
- Trig Offset M -
Power Supply 2 Fan
Tachometer 1
(PS2 Fan Tach 1)
A4h
Chassis-
specific
Fan
04h
Generic –
digital
discrete
01 – State Asserted Non-fatal
As
and
De
- Trig Offset M -
Power Supply 2 Fan
Tachometer 2
(PS2 Fan Tach 2)
A5h
Chassis-
specific
Fan
04h
Generic –
digital
discrete
01 – State Asserted Non-fatal
As
and
De
- Trig Offset M -
Processor 1 DIMM Aggregate
Thermal Margin
(P1 DIMM Thrm Mrgn)
B0h All
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Processor 2 DIMM Aggregate
Thermal Margin
(P2 DIMM Thrm Mrgn)
B1h All
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
