Intel® Server Board S2600CO Family TPS Appendix C: Integrated BMC Sensor Tables
Revision 1.4
Intel order number G42278-004
131
Full Sensor Name
(Sensor name in SDR)
Sensor
#
Platform
Applicability
Sensor Type
Event/
Reading
Type
Event Offset Triggers Contrib. To
System Status
Assert/
De-
assert
Readable
Value/
Offsets
Event
Data
Rearm
Stand-
by
Baseboard +3.3V
(BB +3.3V)
D2h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +5V Stand-by
(BB +5.0V STBY)
D3h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Baseboard +3.3V Auxiliary
(BB +3.3V AUX)
D4h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Baseboard +1.05V Processor
1 Vccp
(BB +1.05Vccp P1)
D6h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +1.05V Processor
1 Vccp
(BB +1.05Vccp P2)
D7h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +1.5V P1 Memory
AB VDDQ
(BB +1.5 P1MEM AB)
D8h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +1.5V P1 Memory
CD VDDQ
(BB +1.5 P1MEM CD)
D9h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +1.5V P2 Memory
AB VDDQ
(BB +1.5 P2MEM AB)
DAh All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +1.5V P2 Memory
CD VDDQ
(BB +1.5 P2MEM CD)
DBh All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +1.8V Aux
(BB +1.8V AUX)
DCh All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +1.1V Stand-by
(BB +1.1V STBY)
DDh All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
