Figure 3. Configuration Jumpers
Password Clear
(J1D2)
1 - 2 Protect password: These pins should be jumpered for
normal operation.
2 - 3 Erase password: If these pins are jumpered for 5 to 10
seconds, the password will be cleared on the next server
reset. These pins should not be jumpered for normal
operation.
Note: The server does not need to be reset with the
jumpers on these pins for the password to be
cleared. To use this jumper to reset the password:
Power down the server. Place the jumper on pins
2 - 3 for 5 to 10 seconds. Move the jumper back to
pins 1 - 2. Power on the server.
BMC Force Update
(J1E3)
1 - 2 Disable force update: These pins should be jumpered for
normal operation.
2 - 3 Enable force update: Jumpering these pins forces a BMC
update.
