2 Intel
®
Server Board S5000PSL
Table 2 summarizes the features of the server board.
Table 2. Server Board Features
Feature Description
Processor support Support for up to two Dual-Core Intel
®
Xeon
®
processor 5000
sequence with a 677-, 1066-, or 1333-MHz front side bus
System memory support
• Eight FBDIMM sockets (DDR2-533 and DDR2-667) supporting
32 GB maximum memory
• Quad-channel memory architecture
Intel
®
5000P Chipset • Product codes S5000PSLSATA, S5000PSLSAS,
S5000PSLROMB: Intel
®
5000P Chipset
• Product code S5000XSLSATA: Intel
®
5000X Chipset
• Intel
®
6321ESB I/O Controller Hub
• Intel
®
5000X Memory Controller Hub
Cooling Support for
• Two processor fans (4-pin headers)
• Four front fans (6-pin headers)
• Two rear fans (4-pin header)
3-pin fans are compatible with all fan headers. 4-pin fans should be
used only with the following fans:
• CPU1 Fan
• CPU2 Fan
• Sys Fan 1
• Sys Fan 2
• Sys Fan 5
• Sys Fan 6
Sys Fan 3 and Sys Fan 4 are connected to the CPU1 PWM, which
is programmed to work with the 4-pin active heatsink fans.
Add-in card slots Six expansion slots:
• One PCI-X* 64-bit / 100-MHz slot
• One PCI-X* 64-bit / 100- / 133-MHz slot
• Two PCI Express* x4 slots
• Two PCI Express x8 slots
Video support
• On-board ATI* ES1000 video controller with 16-MB DDR
SDRAM
• Dual-video is supported
