Intel S5000PSL - Connector and Header Locations

Intel
®
Server Board S5000PSL 5
Connector and Header Locations
AF000247
Q
M
N
O
P
U
R
S
T
OO
QQ
RR
SS
TT
UU
NN
MM
LL
KK
JJ
II
HH
A B D
G
FEC
K
X
CCEE
FF BBDD
GG AA
Z
Y
W
V
H
J
L
I
PP
A. PCI-X* 64-bit, 100-MHz
slot 1
Q. DIMM sockets (see Figure 5
on page 17)
GG. Enclosure management
SAS SGPIO header
(product code
S5000PSLSAS only)
B. PCI-X 64-bit, 100-/133-MHz
slot 2
R. Processor 1 socket HH. Enclosure management
SAS SES2 (product code
S5000PSLSAS only)
C. PCI Express* x4 slot 3 S. Processor 2 socket II. Hot-swap backplane A
header
D. RMM NIC connector T. Processor 2 fan header JJ. SATA 0
E. PCI Express x4 slot 4
(ROMB slot)
U. Processor 1 fan header KK. SATA 1
