Installing the Heatsink(s)
Note: The heatsink has thermal interface material (TIM) located on the bottom of it. Use caution
when handling the heatsink so you do not damage the TIM.
Each processor requires a heatsink. Depending on your chassis, you may need to use
either a passive or an active heatsink. An active heatsink has a fan attached to the top of it
and a cable that needs to be connected to the server board. The following table shows the
Intel
®
server chassis compatible with this server board and whether each chassis requires
an active or a passive heatsink:
Table 5. Heatsink Requirements for Compatible Intel
®
Server Chassis
Server Chassis Heatsink Requirement
Intel
®
Entry Server Chassis SC5299-E BRP Active heatsink
Intel
®
Entry Server Chassis SC5299-E DP
Active heatsink
Intel
®
Entry Server Chassis SC5299-E WS
Active heatsink
Intel
®
Server Chassis SC5400 BRP Passive heatsink
Intel
®
Server Chassis SC5400 LX Passive heatsink
Intel
®
Server Chassis SC5400 Base Passive heatsink
