4 Intel
®
Server Board S5000PSL
RAID support
• One of the following:
– Product code S5000PSLSATA: Intel
®
Embedded Server
RAID Technology II provides SATA RAID 0, 1, and 10 with
optional RAID 5 support provided by the Intel
®
RAID
Activation Key AXXRAKSW5
Note: The Intel
®
RAID Activation Key AXXRAKSW5 will be
available post-launch.
– Product code S5000PSLROMB: Intel
®
Integrated Server
RAID provides eight SAS ports. When the optional Intel
®
Activation KEY AXXRAK18E and RAM are installed,
hardware RAID support is available for RAID 0, 1, 5, 10, and
50. Uses specially keyed PCI Express slot, add-in card slot
4.
– Product code S5000PSLSAS: Intel
®
Embedded Server
RAID Technology II provides SAS/SATA RAID 0, 1, and 10
with optional RAID 5 support provided by the Intel
®
RAID
Activation Key AXXRAKSW5
Note: The Intel
®
RAID Activation Key AXXRAKSW5 will be
available post-launch.
Cooling fan support
• Two 4-pin processor fan connectors
• Four 6-pin front fan connectors
• Two 4-pin rear fan connectors
Management support
• Support for the Intel
®
Local Control Panel (optional component
sold separately)
• Support for Intel
®
Remote Management Module and RMM NIC
(optional component sold separately)
• Support for Intel
®
System Management software
• Intel
®
Light-Guided Diagnostics on field replaceable units
Table 2. Server Board Features
Feature Description
