Intel
®
Server Board S5000PSL 3
Hard drive and optical
drive support
• Optical devices are supported
• Ultra ATA-100 support: One IDE channel that is capable of
supporting up to two drives
• One of the following:
– Product code S5000PSLSATA: Six SATA connectors at 3
GB/s
– Product code S5000PSLROMB: Six SATA connectors on
the server board. Four internal and four external SAS/SATA
ports with expander support from Intel
®
Integrated Server
RAID
– Product code S5000PSLSAS: Four SAS port connectors
and two SATA port connectors, all at 3 GB/s
USB drive support One internal USB port
I/O control support External connections:
• PS/2* ports for keyboard and mouse
• DB9 serial port A connection
• One DH10 serial port B connector (optional)
• Two RJ45 NIC connectors for 10/100/1000 Mb connections:
Dual GbE with Intel
®
I/O Acceleration Technology
(Intel
®
I/O AT) through the Intel
®
8256EB Network Connection
• Four USB 2.0 ports at the back of the board
Internal connections:
• One 9-pin USB header that supports two external USB 2.0
ports
• One internal USB port that supports a peripheral, such as a
floppy drive
• One DH10 serial port B header
• One of the following:
– Product code S5000PSLSATA: six SATA ports at 3 Gbs
– Product code S5000PSLSAS: four SATA / SAS ports and
two SATA ports at 3 Gbs
– Product code S5000PSLROMB: Onboard six-port SATA
controller plus an Intel
®
Integrated Server RAID module in
slot 2 adds four internal and four external SAS ports. The
addition of the Intel
®
RAID Activation Key and a RAID DIMM
adds intelligent RAID 0, 1, 5, 10, and 50.
• One ATA-100 40-pin connector
• One SSI-compliant 24-pin front control panel header
Table 2. Server Board Features
Feature Description
