Feature Summary Intel® Storage System SSR212MA
2 Revision 1.4
Intel
®
Storage System SSR212MA Hardware Feature Summary
Storage Capacity
Expandable to 3.0 TB – using twelve 250 GB drives.
Expandable to 4.8 TB – using twelve 400 GB drives.
Expandable to 6.0 TB – using twelve 500 GB drives.
Expandable to 7.2 TB – using twelve 600 GB drives (future).
Drive Bays
12 Serial ATA (SATA) Hot Pluggable.
Hard Disk Drive
Supported
3.5 inch SATA.
NOTE: For specific drive family and capacities supported, please refer to the
SSR212MA Tested Hardware and OS List (THOL).
Processor
A single Low Voltage Intel® Xeon® processor 2.80 GHz with 1 MB
L2 cache.
Memory Capacity
Expandable to 16 GB maximum, using DDR2-400 memory.
NOTE: Please see memory expansion recommendations in section 1.2 of this
document.
Memory Type
Synchronous Dynamic Random Access Memory (SDRAM),
DDR2-400, Registered, ECC.
DIMM Slots
Six 184-pin DIMM sockets.
Enclosure Controller
On-board Vitesse* VSC055 micro-controller.
Temperature Sensor
Two temperature sensors are located on the backplane that allows drive
cage temperature monitoring by enclosure management.
SATA Compliance
SATA 1.5, 3.0.
Client Connectivity
Client Connectivity via Internet Protocol Small Computer System Interface
(iSCSI) Dual GB Ethernet.
Serial Port
Management console port.
Front Panel
LEDs
Fault, ID, Power.
Back Panel
Buttons and Switches
Power button, Reset button.
I/O Connectors
1x RJ-45 COMB Serial port, 2x RJ-45 Ethernet ports
Power Receptacle
1x IEC AC per installed power supply module.
Chassis
Form Factor
2U rack-mount chassis
Height
86.7 mm, 3.41 in
Width
447 mm, 17.6 in
Depth
631 mm, 24.8 in
Weight
As shipped (zero drives): approximately 16 kg, 35.2 pounds
Fully configured (twelve drives): approximately 27.5 kg, 61 pounds
Shipping container: 3.2 kg, 7 pounds
Color
Black
Rack Support
Rail mount, compatible with four-post rack mount only, and
compliant to the SSI Server Rack specification and EIA 310-D.
System Cooling
Fans
Chassis includes three dual rotor and two single rotor 40 mm hot-
swappable redundant system fans for cooling the hard drives,
