Intel® Storage System SSR212MA Feature Summary
Revision 1.4 3
baseboard and SATA Host Bus Adapter (HBA) cards.
The Power supply enclosure contains one 60mm fan.
Power
Configuration
500 W continuous, 1+1 redundant power supplies. Intel Storage
System SSR212MA ships with one 500W power supply
Max AC input current
(PS Module)
7.2 Amperes at 110 Vrms, 3.5 A at 220 Vrms (each power supply
module)
Max +3.3 V output
(PS Enclosure)
20.0 A
(total combined power for the+ 3.3 V and +5 V outputs should not
exceed 120 W).
Max +5 V output
(PS Enclosure)
20.0 A
(total combined power for the+ 3.3 V and +5 V outputs should not
exceed 120 W).
Max +12 V output1
current
(PS Module)
18.0 A
(total combined power for the +12 V outputs should not exceed
360 W).
Max +12 V output2
current
(PS Module)
18.0 A
(total combined power for the +12 V outputs should not exceed
360 W).
Max +12 V output3
current
(PS Module)
18.0 A
(total combined power for the +12 V outputs should not exceed
360 W).
Max -12 V output
current
(PS Module)
0.5 A (each power supply module)
Max +5V Standby
output current
(PS Module)
2.0 A (each power supply module)
Environment
Ambient Temperature
Operating (system): 10 degrees Celsius to +35 degrees Celsius,
with maximum change not to exceed 10 degrees Celsius per hour;
non-operating (system): -40 degrees Celsius to +70 degrees
Celsius.
Relative Humidity
Non-operating: 90% @ 35 degrees Celsius non-condensing
Acoustics
< 7.0 BA (rack-mount) in an idle state in an normal office
environment (23 degrees Celsius)
Electrostatic
Discharge
15 KV per Intel test specification
Safety Compliance
Argentina
IRAM
Canada
UL60950 – CSA (60950 (UL and cUL)
China
GB4943- CNCA Certification
Europe, CE Mark
EN60950 (complies with73/23/EEC)
Germany
GS License
International
IEC60950 (CB Report and Certificate)
Nordic Countries
EMKO-TSE (74-SEC) 207/94
Russia
GOST 50377-92
