3.19. Sensor connection conguration (valid for versions 1.80 and up)
Type Conguration for the center zones Conguration for XEZ zones
0 Single zone without end-of-line resistor Single zone without end-of-line resistor
1
Single zone without end-of-line resistor and
with tamper detection
Single zone without end-of-line resistor and
with tamper detection
2
Single zone with end of line resistor and wiring
short circuit detection
Single zone with end of line resistor and wiring
short circuit detection
3
Single zone with end of line resistor, tamper and
wiring short circuit detection
Single zone with end of line resistor, tamper and
wiring short circuit detection
4 Dual zone without end-of-line resistor Dual zone without end-of-line resistor
5
Dual zone without end-of-line resistor and with
tamper detection
Dual zone without end-of-line resistor and with
tamper detection
6
Dual zone with end-of-line resistor, tamper and
wiring short-circuit detection
Dual zone with end-of-line resistor, tamper and
wiring short-circuit detection
7
Parallel doubling with wiring short-circuit
detection
Single zone with end-of-line resistor and wiring
short-circuit detection
Enter + 54 + ? + Enter
? = connection type from 0 to 7
0 = Single zone without end-of-line resistor
1 = Single zone without end-of-line resistor and with tamper detection
2 = Single zone with end of line resistor and wiring short circuit detection
3 = Single zone with end of line resistor, tamper and wiring short circuit detection
4 = Dual zone without end-of-line resistor
5 = Dual zone without end-of-line resistor and with tamper detection
6 = Dual zone with end-of-line resistor, tamper and wiring short-circuit detection
7 = Parallel doubling with wiring short-circuit detection
3.20. Presence Announcer
Enter + 55 + ? + Enter + select zone + Enter
? = zone group from 0 to 7
0 = zones 1 to 8
1 = zones 9 to 16
