Intellian i4 Inland User Manual

62
Intellian Satellite TV Antenna Systems
General
Approvals
CE – conforms to
FCC – veried to
EU Directive 89/336/EEC
CFR47:Part 15
Dimensions
Satellite antenna unit
Antenna dish diameter
Antenna control unit
50cm (19.7”) x 54cm(21.2”)
45cm(17.7”)
17.8cm(7”)x21.7cm(8.5”)x5.4cm(2.1”)
Weight
Satellite antenna unit
Antenna control unit
11.6kg (21.5 lbs)
1.2kg (2.6 lbs)
Environmental
Operating temperature range
Storage temperature range
Humidity limit
-15°C to +55°C (+5°F to +131°F)
-25°C to +70°C (-13°F to +158°F)
95% R.H
Operating voltage 100V ~ 220V AC
Power consumption Typ. 30W, Max. 50W
Antenna system performance
Frequency Ku-band (10.7 to 12.75 GHz)
Minimum EIRP 49dBW
Azimuth range 680°
Elevation range 0° ~ +90°
Ship’s motion
Roll ±25°
Pitch ±15°
Roll and pitch
response rate
50° per second
Turn rate 50° per second
Appendix : i4 Inland Technical Specication
